Toolbar, ToolbarItem, ToolbarItemGroup, and Menu in SwiftUI

SwiftUI provides a powerful and intuitive way to add and customize toolbars in your app’s user interface.

Toolbar in SwiftUI

Let’s create a simple  app interface in SwiftUI that allows users to change the color and font size

struct ContentView: View {

    @State private var selectedColor: Color = .black
    @State private var fontSize: CGFloat = 15.0

    var body: some View {

        NavigationStack {
            ZStack {
                // Placeholder for drawing canvas
                Color.white
                VStack {
                    Spacer()
                    Text("UIExamples.com")
                        .foregroundColor(selectedColor)
                        .font(.system(size: fontSize))
                    Spacer()
                }
            }
            .toolbar {
                ToolbarItemGroup(placement: .bottomBar) {
                    ColorPicker("Font Color", selection: $selectedColor, supportsOpacity: false)
                        .padding()

                    Slider(value: $fontSize, in: 10...20) {
                        Text("Font Size")
                    }
                    .frame(width: 150)
                }
            }
        }
    }

}

ToolbarItem

ToolbarItem is used to place individual items or actions within a toolbar. You can specify the placement of these items and customize their content.

Example: Adding a Button to the Toolbar

struct ToolbarItemExample: View {

    @State private var text: String?

    var body: some View {

        NavigationStack {
            Text(text ?? "")
                .navigationTitle("ToolbarItem Example")
                .toolbar {
                    ToolbarItem(placement: .navigationBarTrailing) {
                        Button(action: {

                            print("Action button tapped!")

                            text = "UIExamples.com"

                        }) {
                            Image(systemName: "plus")
                        }
                    }
                }
        }
    }
}

In this example, a ToolbarItem is added to the navigation bar’s trailing edge, represented by a plus icon.

Grouping Multiple Toolbar Items with ToolbarItemGroup

struct SwiftUIToolbarContentExample: View {

    @State private var text: String?

    var body: some View {
        NavigationStack {
            Text(text ?? "")
                .navigationTitle("ToolbarContent Example")
                .toolbar {
                    ToolbarItemGroup(placement: .bottomBar) {
                        Button("First") { print("First button tapped")

                            text = "UIExamples.com: First button tapped"

                        }
                        Spacer()
                        Button("Second") { print("Second button tapped")

                            text = "UIExamples.com: Second button tapped"

                        }
                    }
                }
        }
    }
}

ToolbarItemPlacement and ToolbarTitleMenu

ToolbarItemPlacement defines where a toolbar item should be located. ToolbarTitleMenu is not a direct SwiftUI component but can be achieved by using a ToolbarItem with specific placement to create a menu in the toolbar title’s vicinity.

Example: Creating a Menu in the Toolbar

struct ToolbarMenuExample: View {

    @State private var text: String?

    var body: some View {
        NavigationStack {
            Text(text ?? "")
                .navigationTitle("Title")
                .toolbar {
                    ToolbarItem(placement: .navigationBarLeading) {
                        Menu("Options") {
                            Button("Option 1", action: { print("Option 1 selected")

                                text = "UIExamples.com: First button tapped"

                            })
                            Button("Option 2", action: { print("Option 2 selected")

                                text = "UIExamples.com: Second button tapped"

                            })
                        }
                    }
                }
        }
    }
}

In this example, a Menu is placed in the navigation bar’s leading edge using a ToolbarItem. This creates a dropdown menu with options, mimicking the functionality of a title menu.
